D-1
Precision Forged · 1-piece
Precision Forged
D-1
from $568
per wheel
Size · Select a size
Vehicle Fitment
MakeLoading makes…▾
ModelPick a make first▾
YearPick a model first▾
TrimPick a year first▾
- Wheels ·
- Not handed
Only one of each is left, so there is nothing to choose here.
1
Specification
Your Selection—
Finish—
Size
Wheel Spec—
Lug Count8-lug
Bolt Pattern8×165.1 · 8×200 · 8×210
Offset (ET)ET −202 to 105
ProcessPrecision Forged
Centre Bore116.7 / 121.6 / 142.2 / 154.3 mm
Load Rating3,700 lbs
Bump ProfileH2
Rim ProfileJ
Cap CodeCP461HPS200C · CP461HPS200K · CP461PS160C · CP461PS160K
Wheel Dimension Diagram
⌀ 22"WIDTH 8.5"Holes
8
PCD
165.1
Spokes
5
Bore
121.6 mm
ET
—
What it fits
| Size | Bolt pattern | Offset | Load |
|---|---|---|---|
| 22 × 8.5 | 8×165.1 | +105 | 3,700 lbs |
| 22 × 8.5 | 8×200 | +105 | 3,700 lbs |
| 22 × 8.5 | 8×210 | +105 | 3,700 lbs |
| 22 × 8.5 | 8×165.1 | −202 | 3,700 lbs |
| 22 × 8.5 | 8×165.1 | −192 | 3,700 lbs |
| 22 × 8.5 | 8×200 | −202 | 3,700 lbs |
| 22 × 8.5 | 8×210 | −202 | 3,700 lbs |
Checked on bolt pattern, offset, hub bore and load rating.
